dB Technologies SYA 10 2-Yollu 10-inch 400 Watt Aktif Kabin Hoparlor

dB Technologies SYA 10 2-Yollu 10-inch 400 Watt Aktif Kabin Hoparlor

Active 2-way speakers

Bluetooth®connection

3 Channel IN

1 link OUT with link/mix switch

Linear Phase FIR Filters for accurate sound reproduction

DSP presets for wide versatility

Soft cover included

Acoustical data

Frequency Response [-10dB]55 - 18.000 Hz

Max SPL125 dB

HF1" CD, 1"v.c

LF10", 2" v.c.

Dispersion90°x60°

Crossover Frequency2000 Hz (24 dB/oct.)

Amplifier

Amp TechnologyClass D(LF)+Class AB (HF)

Power Peak (LF+HF)400 W

Processor

Controls1xVolume, 1xslide switch mic/line

Indicatorspower on/signal/limiter LEDs

ControllerDSP 20/56 bit

AD/DA Converter24 bit/ 48 Hz

Systems PresetsPlayback, Flat, Bass Boost, Wedge

LimiterPeak, RMS, Thermal

Advanced DSP FunctionsLinear Phase FIR Filters

Input

Signal Input1x Combo(XLR/Jack)

Mic/Line

1xXLR/TRS

Bluetooth Input1xBluetooth receiver

SIGNAL Out1xXLR Male (LINK/MIX)

Mechanics

HousingPolypropylene

Handles3 (2 on side 1 on top)

Angles UpMonitor Use 40°

Pole Mount36 mm, double positioning

Width310 mm (12.2 in)

Height521 mm (20.51 in)

Depth292 mm (11.51 in)

Weight11.7 kg (25.79 lbs)
